The first image of what appears to be the GeForce RTX 5090 “Blackwell” graphics card has surfaced, offering a glimpse into the successor of the RTX 4090 “Ada.” This image aligns with the bare PCB leaks that were circulating over the weekend. The RTX 5090 will reportedly be powered by the “GB202” silicon, the largest gaming GPU built on NVIDIA’s “Blackwell” architecture. The GPU package in the image displays an ASIC code of “GB202-300-A1,” suggesting that the RTX 5090 might not utilize the full potential of the silicon, as NVIDIA’s fully enabled GPUs typically carry the designation “450.”
Memory Configuration and Bus Width
The “GB202” silicon is accompanied by sixteen GDDR7 memory chips, which are said to deliver a total of 32 GB of video memory. This arrangement, combined with the GPU’s large package size and pin layout, confirms a 512-bit wide memory interface. If the memory operates at 28 Gbps, the resulting memory bandwidth would reach an impressive 1,792 GB/s, positioning the RTX 5090 as a significant upgrade in memory performance over its predecessor.
Power and VRM Design
The PCB layout also highlights a robust 24-phase VRM design, tasked with managing power delivery for the GPU and memory modules. The card draws power through a single 16-pin 12V-2×6 power connector. Given NVIDIA’s history of pushing the power limits of its flagship GPUs, it is expected that the RTX 5090 will utilize the full 600 W continuous power delivery capacity of this connector. The total graphics power (TGP) is likely to be in the range of 500-550 W, though higher figures cannot be ruled out.
Implications for Performance
The design and specifications of the RTX 5090 suggest that it will aim to deliver substantial performance gains. The combination of the “GB202” GPU, high-bandwidth GDDR7 memory, and advanced power delivery indicates that NVIDIA is targeting the high-end gaming and professional graphics markets with this release. However, the exact performance metrics and feature set will only become clear closer to the official launch.
Our Verdict
The leaked image of the RTX 5090 provides valuable insights into NVIDIA’s next-generation GPU strategy. With advancements in memory technology, a wider bus interface, and a powerful VRM setup, the RTX 5090 “Blackwell” is shaping up to be a formidable addition to NVIDIA’s GeForce lineup. Further details, including performance benchmarks and availability, are anticipated as the official announcement approaches.
